Overview of Cone Valve Filling Industrial Pump
Cone valve filling industrial pump is a hydraulic plug pump specially used for conveying high solid content mud like materials, widely used in mining tailings filling and other fields. The following is a detailed introduction to the cone valve filling industrial pump:

working principle
The working principle of the cone valve filling industrial pump is mainly to control the pumping process by changing the gap between the valve core and valve seat of the cone valve to connect and disconnect the oil circuit. Specifically, the high-pressure oil pumped out by the hydraulic pump drives the piston rod of the main cylinder to move back and forth, and the conveying piston in the conveying cylinder is connected to the piston rod of the main cylinder and also moves back and forth with each push and pull. When the main oil cylinder piston rod drives the conveying piston to retreat, the conveying material is sucked into the conveying cylinder; When the piston rod of the main oil cylinder drives the piston forward, the conveying material that is first sucked into the conveying cylinder is pressed into the conveying pipeline through the cone valve.

Main components
The cone valve filling industrial pump is mainly composed of pump body, cone valve component, driving device, and control system. Among them, the cone valve component is a key component of the pump, which controls the flow of fluid through the opening and closing of the cone valve, achieving precise flow and pressure regulation. The pump body is responsible for providing fluid channels and supporting other components, while the driving device provides power to drive the cone valve assembly and pump body.

Technical features
The cone valve has a simple structure, low wear and tear, and low failure rate: The cone valve filling industrial pump adopts a cone valve design, which has a simple structure, low wear and tear, low failure rate, and improves the operational stability and service life of the pump.
The large diameter of the material cylinder facilitates the suction of materials with low water content, resulting in high material suction efficiency: The larger diameter of the material cylinder facilitates the suction of materials with low water content, improving the material suction efficiency and thus enhancing the overall pumping capacity.
The system controls the number of reversals per minute within 8 times, resulting in low wear and long service life of vulnerable parts. The system controls the number of reversals per minute within 8 times, reducing wear and extending the service life of vulnerable parts.
The material cylinder is chrome plated, and the oil cylinder seal adopts an imported 7-way combination seal with good sealing to prevent debris from entering the hydraulic system. The material cylinder is chrome plated to improve wear resistance; The oil cylinder seal adopts an imported 7-way combination seal, which is well sealed and effectively prevents debris from entering the hydraulic system, ensuring the normal operation of the pump.
The piston head is made of high-quality polyurethane with a service life of over 1 million times: The piston head is made of high-quality polyurethane material with good wear resistance and a service life of over 1 million times.
